PROTECTOR™ SERIES HEAVY DUTY Flush Floor Box, Flush, Square Edged, Stainless Steel
CAT NO. FB1SHD
| Features: | Load rated with Cable Shield® suitable for vehicle traffic |
| Capacity: | 1 standard size GPO and 1 No. 3 Gang Data Plate |
| Box Size: | 150 x 150 x 115 mm Deep |
| Lid Material: | Stainless 304 – No. 4 Linished |
| Suitable for: | Compact installations |
Key Features
- Heavy duty – load rated floor box suitable for vehicular traffic.
- Ideal for car showrooms and shopping centres.
- Flush Protector™ Series Stainless Steel lid and frame with No. 4 Linished finish.
- Protector™ Series features Cable Shield® Frame assembly to prevent cables being cut. (Patent Certified 2017100897 & Patent Pending 2015204344)
- Frame has square edges (not bevelled) to allow flush fitting to adjacent floor finish (typically timber, tiles or vinyl).
- Robust and large capacity cable exit flap with retracing lifting handle.
- Capacity for 1 x standard D/GPO and 3 x Data.
- Supplied with temporary construction lid.
- This product has been examined in accordance with AS 3000 and conforms to A.C.M.A. requirements.
